Handle, levers & catcher system – Hustler Turf M-1 User Manual
Page 43
108548_1208
6-17
Handle, Levers & Catcher System
NOTES:
ITEM
NO.
SERVICE PART
NO.
QTY.
DESCRIPTION
ITEM
NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
51027-268-103
1
HANDLE
28
11095-117
1
LEVER
2
51027-280-103
1
HANDLE
29
31062-109
1
PRE-COAT LOCK BOLT
3
11095-172
1
LEVER
30
31057-281
1
HEX BOLT
4
36110-102
1
BUTTON
31
68036-125
1
WASHER
5
11049-109
1
SLIDE PLATE
32
563L-0600
1
U-HEX CAP NUT
6
64014-336
1
SHAFT
33
71285-109
1
HOLDER C.P.
7
376L-0612
1
TRUSS SCREW
34
68013-161
1
SPRING
8
71203-135
1
ARM C.P.
35
71900-796
1
COVER ASSEMBLY
9
76007-183
1
BUSHING
36
470L-0514
2
TAPPING SCREW
10
68013-371
1
SPRING
37
71900-845
1
BOLT SET
11
31056-127
1
GIB-HEADED PIN
38
569L-0800
4
FLANGE NYLON NUT
12
576V-0600
1
PUSH NUT
39
31057-256
2
HEX BOLT
13
68013-392
1
SPRING
40
583L-0800
6
FLANGE CAP NUT
14
11109-111
1
LINK
41
71900-846
1
BAR SET
15
61023-190
1
SLEEVE
42
11012-132
2
HANGER BAND
16
64014-337
1
SHAFT
43
31057-181
2
HEX BOLT
17
812V-0800
1
C-SNAP RING
44
68028-118
3
WIRE BAND
18
613L-0800
2
WASHER
45
91003-125
1
CONTROL CABLE
19
71161-120-09
1
LEVER ASSEMBLY
46
91003-180
1
CONTROL CABLE
20
NSS
1
LEVER
47
91001-329
1
THROTTLE WIRE
21
76007-131
1
BUSHING
48
91003-169
1
CONTROL CABLE
22
76007-191
1
BUSHING
49
11062-178
1
FRAME C.P.
23
68013-391
1
SPRING
50
36098-155
1
GRASS BAG C.P.
24
91010-169
1
THROTTLE LEVER
51
41003-201
1
TUBE
25
61003-113
1
THRUST PLATE
52
68028-119
2
WIRE BAND
26
68013-356
1
SPRING
53
36080-156
1
RUBBER SHEET
27
31058-168
1
HEX NUT
