PARTS LIST - See Hardware Identifier
Item Qty. Part No. Description
1
1
904847
Top Pole Section (Black)
2
1
978482
Middle Pole Section (Black)
3
1
900284
Bottom Pole Section (Black)
4
1
206615
Base
5
4
226401
Wheel
6
1
200628
Wheel Axle, 11-3/4 Long
7
1
202820
Rod, 3/8 x 4-3/4 Long
8
1
206934
Eyebolt
9
1
206949
Pivot Bracket, Upper
10
3
203063
Lock Nut, 3/8-16 Nylon Insert
11
2
906410
Base Strut (Black)
12
1
202541
Bolt, Hex Head 5/16-18 x 3-3/4 Long
13
10*
203218
Washer, Flat, 3/8 I.D.
14
13*
203100
Nut, Hex Flange 5/16-18
15
1
203220
Lock Nut, 5/16-18 , Nylon Insert
16
2
203798
Bolt, Hex Flange, 5/16-18 x 1-1/2 Long
17
1
206948
Pivot Bracket, Lower
18
2
206252
Bolt, Hex Head, 3/8-16 x 1 Long
19
1
203330
Bolt, Hex Head, 3/8-16 x 4-1/2 Long
20
1
906606
Handle Bar
21
1
900223
Wheel Bracket
22
4
203103
Carriage Bolt, 5/16-18 x 2 Long
23
1
206604
Handle, Back Plastic
24
1
206940
Axle
25
2
206938
Push Cap
26
1
206605
Handle, Front Plastic
27
4
204804
Screw, Phillips Head, 3/4” Long
28
1
206956
Disc, 5” O.D. x 13/32 I.D., Plastic
29
2
900964
Bracket, Elevator Mount
30
2
200874
Spacer, Steel .402 I.D.x.50 O.D.x1.5 Long
31
4*
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
32
4
201642
Spacer .530 I.D. x.63 O.D. x .63 Long
33
4*
206360
Bolt, Hex Head, 3/8-16 x 2-5/8 Long
34
5
201124
Lock Nut, Hex Head, 3/8-16
Item Qty. Part No. Description
35
2
904821
Elevator Tubes, Lower - Long
36
6
206304
Bolt, Hex Head, 1/2-13 x 6-5/16 Long
37
4
206311
Spacer, Plastic, .530 I.D. x .50 Long
38
6
206340
Lock Nut, Hex Head, 1/2-13
39
1
203038
Carriage Bolt, 5/16-18 x 2-3/4 Long
40
2
904808
Elevator Tube, Upper - Short
41
1
202814
Cap, Pole Top
42
1
204837
Spring
43
12
201219
Smart Clip, Net Holder
44
2
203617
Cap, Base Tank (Plastic)
45
1
201568
Anchor, T-Strap
46
1
203124
Stake, Tie Down
47
1
201253
Label, Height Adjustment and Moving
48
1
204855
Handle, Left
49
1
204856
Handle, Right
50
1
204803
Screw, Phillips Head
51
1
904833
Height Adjustment Rod
52
1
204872
Label, Height Indicator
53
1
204832
Bracket, Pole Mount
54
2
203231
Carriage Bolt, 5/16-18 x 3-1/2 Long
55
2
204857
Spacer, Metal 1/2” O.D.x1.44 Long
56
2
204858
Spacer, Biscuit, Plastic
57
4
220154
Washer, Metal, 3/4” O.D.
58
2
204859
Cover, Pin Slide
59
1
204853
Lanyard, Black Coil
60
1
204850
Pin, Locking
61
1
Rim
62
1
Net
63
1
200627
Wheel Carriage
64
2
201651
Spacer Plastic, Wheel Axle
65
1
206990
Bracket, Reinforcement
66
2
203217
Carriage Bolt, 5/16-18 x 1 1/2 Long
* You may have extra parts with this model.
WARRANTY CARD:
Please remember to complete your product
registration form either
on-line at: www.huffysports.com/warrantycard
or mail-in the enclosed postcard.
WARNING: IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC
BACKBOARD, EXAMINE BACKBOARD FOR ANY DAMAGE THAT MAY
HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD
COULD RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS DAMAGED
IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE
NUMBER FOR FREE REPLACEMENT:
U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com
