Specification – Hyundai H-CMD4004 User Manual
Page 41
41
Specification
General
Power supply:
12 V DC
Current consumption:
max. 15 A
Maximum power output:
50 W x 4 channels
Compatible formats:
DVD/SVCD/VCD/HDCD/MP3/WMA/Picture-CD/JPEG
playback/MPEG4
Supported storages:
CD-R/-RW/DVD±R/±RW
Dimensions (L x W x H):
165 x 178 x 50 mm
Working temperature range:
-10º - +60º
ESP function:
40 sec. for Audio CD, 120 sec. for MP3
TFT display
Screen size:
4 inch
Resolution:
480x272 dpi
Aspect ratio:
16:9
Contrast ratio:
300:1
Brightness:
350 cd/m2
View angle:
V: 1200, H: 1200
FM Stereo Radio
Frequency range:
65.0 – 74.0 / 87.5 – 108.0 MHz
Usable sensitivity:
6 uV
Preset memory stations:
18
AM section
Frequency range:
522 kHz - 1620 kHz
Preset memory stations:
12
Audio specification
Maximum output:
2 Vrms (+/- 3 dB)
