Page 2 SKU 96406 for technical questions, please call 1-800-444-3353
specifications
Jack Construction 10 Gauge Sheet Steel Plate
Crank Handle Construction
and Dimensions Steel Rod Rubber Grip and Attached Socket
25-3/4” L X 15/32” Diameter (5” Long Rubber Handle and Grip)
Jack Capacity 5000 lb. maximum capacity with height not less than 13-3/4”
Lift Range 4-5/8” Minimum Height to 23-1/2” Maximum Height
Overall Dimensions 26-1/4” Total Length X 4-5/8” High X 6-3/4” Wide (Collapsed for Storage)
Jack Mounting
Bolt-On (see directions on page 5 of this manual)
Weld-On (see directions on page 5 of this manual)
Unmounted use is NOT recommended
Weight 14.35 lb. (Jack Only)
save this Manual
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep your
invoice with this manual. Write the invoice number on the inside of the front cover. Write the
product’s serial number in the back of the manual near the assembly diagram, or write month
and year of purchase if product has no number. Keep this manual and invoice in a safe and
dry place for future reference.
safety ruLes and warnings
warning!
read and understand aLL instructions
failure to follow all instructions listed below may result in
serious injury.
save tHese instructions
do not use tHis LeveLing jack for Lifting. Do not use to change tires.
keep space around jack as uncluttered as possible when using this Leveling
scissor jack. Clutter can hinder smooth operation and possibly cause accidents
and/or serious personal injury. Keep area well lit.
keep out from under trailer or rv. Keep hands away from scissor mechanism.
do not exceed maximum weight capacity of 5000 lb.
wear ansi-approved safety goggles and heavy duty work gloves during use.
Level only at trailer or rv manufacturer’s recommended lifting points.
install this Leveling scissor jack in accordance with dMv regulations.
keep children away. Children must never be allowed in the Leveling Jack area. Do
not let them handle the Jack at any time.
