Page 10 For technical questions, please call 1-800-444-3353. Item 00996
Part Description
1 Load chain
2 Suspension plate
3 Stay A
4 Load chain wheel
5 Drive shaft
6 Splined gear
7 Pinion shaft
8 Disk gear
9 Hand wheel
10 Brake seat
11 Friction
12 Roller gear
13 Bearing race
14 Ratchet disc
Part Description
15 Hand chain
16 Pawl spring
17 Pawl
18 Hand wheel cover
19 Snap ring
20 Pawl pin
21 Left side plate
22 Suspension plate
23 Suspension pin
24 Dam board
25 Snap ring
26 Pin
27 Guide roller
28 Steel sheath
Part Description
29 Stay B
30 Hook hanger
31 Bent plate
32 Roller
33 Sheet cover
34 Shaft
35 Needle
36 Idle sheave
37 Hook holder
38 Hook
39 Latch kit
40 Double spring
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
