Parts list – Hayter Mowers Ranger 415A User Manual
Page 30
42
Plug - Drive Small
300144
4
43
Ratchet - HOC
415014
1
44
Decal - HOC
320006
1
45
Screw - Self Tap Engine
09349
3
46
Underdeck - Assy
410015
1
Inc. 21,47,48,50
47
Chute
410058
1
48
Nutsert
410076
1
49
Cover - Underdeck
410060
1
50
Throwplate
410059
1
51
Axle - Front W/A
410051
1
52
Bearing - Front Axle
410069
2
53
Hub - Cap
219143
4
54
Nut - Nyloc 1/2" UNF
4486
4
55
Wheel
5218
2
56
Bolt - Cutterblade
09788
1
57
Washer - Spring
09273
1
58
Distance Piece - Cutterblade
4014
1
59
Carrier - Blade Boss
410073
1
60
Friction Disc
410057W
1
61
Cutter Blade
201026
1
62
Washer - Plain
09262
1
63
Rod - Connecting
410049
1
64
Spring - Counter Balance
410050
1
65
Push fix
0201086
3
66
Frame - Push
415001W
1
67
Screw - Taptite M6 x 35
09786
2
68
Spring - HOC
480132
1
69
Lever - HOC
480128
1
70
Housing - Bearing Support
410048
1
71
Bracket - Roller Support LH
410002
1
72
Grip Fix - 5/16” L.D.
04020
1
73
Plate - Securing
219037
1
74
Box Battery
410080
1
75
Decal - Hayter
410065
1
76
Bracket - Roller Support RH
415010
1
77
Plate Axle Tie
415015
1
78
Cover - Nut M6
343025
2
1.30
PARTS LIST
ITEM NO. DESCRIPTION
PART NO.
QTY.
ITEM NOTE
