Speaker Size
Many of today’s receivers allow you to tell the receiver what type of speakers you are using. This is important since you
don’t want to waste the power across a full-frequency signal to a speaker that can only handle a limited range. Receivers
will typically ask you whether or not the speaker is “small” or “large”. In most cases, setting the speaker to “small” will
cause only frequencies above 100 Hz to be sent to the speaker. “Large” allows the full frequency range to be passed to
the speaker. Some receivers take this a step further and actually allow you to set the cut-off frequency. HTD Level ONE
speakers will almost always perform best when set to “small” or with a crossover point of 100 to 120 Hz.
In many receivers, setting a speaker to “small” automatically sends the low frequencies that would otherwise go to that
channel to the subwoofer connected to the LFE channel. Check the “bass management” section of your receiver’s
owner’s manual to be sure. This section should also address the options you have for utilizing the powered subwoofer in
audio-only applications.
Mounting Brackets
HTD Level ONE Main Speakers include U-shaped wall-mount speaker brackets. Hardware is included for mounting
where you have access to both sides of the wall or stud. You can also attach the speaker brackets to a stud from one side
using 1 1/2” wood screws. For safety, always mount these speakers on a wall that is reinforced from behind. Never
mount a speaker on a wall made of un-reinforced drywall or plasterboard. Consult a professional contractor if you are
unsure. These speakers can also be placed on bookshelves and most types of speaker stands.
NEVER PLACE A SPEAKER WHERE IT, OR THE CABLE CONNECTED TO IT, ARE WITHIN EASY REACH OF
CHILDREN OR PETS. ALWAYS USE GOOD JUDGEMENT AND COMMON SENSE WHEN PLACING A SPEAKER
WHERE PEOPLE OR PETS WILL HAVE ACCESS TO IT AS SERIOUS INJURY OR DEATH CAN OCCUR IF THE
SPEAKER WERE TO FALL.
Warranty
All HTD Speakers carry a five-year parts and labor warranty. Details of the warranty and return authorization process are
available on our web site. Your warranty registration occurred at the time your order was placed. There is no need to fill
out additional forms.
From all of us at Home Theater Direct, thank you for choosing HTD!
Level ONE Mains
HTD-A10
Level ONE Center
HTD-C10
Level ONE Subwoofer
HTD-S10
Frequency Response 80 Hz – 20 kHz 80 Hz – 20 kHz 30 Hz – 250 Hz
Power Capacity 80 watts 80 watts 80 watts
Impedance 8 ohms 8 ohms --
Sensitivity 89 db 89 db --
Video Shielding NO YES NO
Driver 4” polypropylene (2) 4” polypropylene 8” reinforced
Tweeter 3/4” polycarbonate dome 3/4” polycarbonate dome --
Connections binding posts binding posts Line-level inputs; Speaker
level inputs and outputs
Dimensions (HxWxD in.) 8 1/2 x 6 x 6 15 1/2 x 6 x 6 13 1/2 x 11 3/4 x 11 3/4
Weight (lbs / each) 3.1 6.0 17
