Installation and adjustment
Please install and adjust the machine according to the requirement of the mannual.
It is very important to your security and correct operating the machine.
After opening the package, please lean the washing
machine gently down on soft items (like towel cloth,
blanket, etc.). Install the bottom plate to the bottom of
the machine with eight screwsby a cross screwdriver,
then lift the machine up gently. See to the figure:
Install the inner cover component
Install the bottom plate
Inner cover
Inner cover shaft
Outer tub cover
Section
I enlarging
Push
Outer tub cover
shaft groove
1.Open the top lid of the washing machine.
2.Put the inner cover component on the outer
tub cover, aiming the inner cover shaft to
the installation hole of the corresponding
outer tub cover shaft groove.
3.Firstly insert the inner cover shaft of one side into the
corresponding outer tub cover shaft groove, then push
the another inner cover shaft into the corresponding
outer tub cover shaft groove. Please install to designated
position to guarantee there are no dropping or abnormal
sound in opening and closing of the inner cover, and the
operation shall be smooth. Do not dismount the inner
cover component after washing.
Shock pad
The washing machine away from wall should be overrun 20mm. The largest allowable slope of the
shank base of the machine is 2
.The slanting or rough ground will result inunstable running or
stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal:
Hang the lead line to check if it is
horizontal.
Adjust the adjustable leg:
Adjust the Installation position
Fasten
Loosen
High Low
the adjustable nut
the adjustable feet
1 .To twist the adjustable leg, please first lift up the
side of the leg slightly, loosen the adjustable nut,
and twist the leg.
2 . After adjustment, fasten the nut.
Soft object
Bottom plate
Back
Screw
Front
