Parts List

Index

Description

Quantity

1

ramp

1

2

ramp bolt sets

2

3

Carriage bolt sets

2

4

Ramp bracket

1

5

Spring pull pin

2

6

reflector

2

7

carrier tray

1

8

gear

1

9

hitch pin

1

10

M12x70 bolt

1

11

adjust bolt

1

12

M10x30 bolt

3

13

anti tilt lock bracket

1

14

lock bolt

4
