First Setup
Congratulation for purchasing this monitor of high performance!
This monitor comes with the following accessories :
Quick Installation
1. Connect video cable (D-Sub cable)
Make sure both monitor and computer are powered OFF. Connect the video
cable ( D-Sub cable) to the computer.
3 . Connect power cord
Connect the power cord to a properly grounded AC outlet, then to the monitor.
4 . Power-ON computer and monitor
Power-ON the computer, then Power-ON the monitor.
5 . Windows users: Setting the Timing Mode (Resolution and Refresh Rate)
Example: 1280 x 1024 @ 60 Hz
Resolution Right-click on the Windows desktop > Properties > Settings >
“Desktop Area”. Set the resolution.
Refresh Rate (vertical frequency) See your graphic card’s user guide for
instructions.
Example:
Power cable
2
D-Sub cable
Power cable.
D-Sub cable (15 pin)
Audio cable.
User manual.
2. Connect DVI cable
Connect the DVI cable from DVI output of computer to the DVI input of the
monitor.
