Honorable users,
Thanks for your choosing Haier products.
To facilitate your operation, please read the manual carefully and operate this machine
according to it.
Haier-sincere forever!
Names of the parts
Before using Before using
Softener injection inlet
Bleach injection inlet
Adjustable feet
(4)
Cabinet
Control panel
Control panel seat
Inner tub
Top lid
Power line
Cold water inlet valve
Water absorption cushion
Meaning and description of the symbols
Water inlet hose
(2)
Outer drain hose component
(1)
Drain hose clamp
(1)
Drain hose hook
(1)
Warning sign
Forbidding sign
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strict conformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Accessories
Door switch
Agitator
Drain hose joint
Please understand the shapes of the washing machine and accessories may be different
from the sketch figures in this manual due to product improvement.
Hot water inlet valve
