Page 33
31
TRANSPORTING
BEFORE LOADING
If the engine has been running, allow it to cool for
at least 15 minutes before loading the tiller on the
transport vehicle. A hot engine and exhaust
system can burn you and can ignite some
materials.
1. Turn the engine switch to the OFF position.
2. Make sure the fuel cap is securely tightened.
3. Install the wheels to provide added stability
when transporting (see page 9).
LOADING
If necessary, loosen the handlebar knobs so that
the tiller upper handlebar can be collapsed
forward over the engine. Be careful that the
throttle cable and engine switch wire are not
pinched or bent when collapsing the upper
handlebar.
Secure the tiller by tying around the lower
handlebars just in front and back of the engine.
UPPER
HANDLEBARS
THROTTLE
CABLE &
ENGINE
SWITCH WIRE
TIE DOWN
HERE
HANDLEBAR
KNOBS
