CONTROLS & EQUIPMENT
9
Transport Wheels
The transport wheels are used to move the tiller
around. Before tilling, the transport wheels must be
removed and the drag bar installed in their place.
Carrying Handle
Hold the carrying handle when starting the engine.
The carrying handle can be used to load/unload the
tiller, and to assist in certain engine maintenance
procedures.
Recoil Starter Grip
Pulling the starter grip operates the recoil starter to
crank the engine for starting.
Drag Bar
The drag bar is used to control the forward action of
the turning tiller tines. The drag bar can be adjusted to
control the tilling depth of the tines.
Narrow Cultivating
The two outer tines can be removed to give you a
narrower cultivating width. This gives you the ability to
get between very closely spaced plants.
TRANSPORT
WHEELS
RECOIL
STARTER
GRIP
CARRYING
HANDLE
DRAG BAR
