TECHNICAL & CONSUMER INFORMATION
63
Maintenance
Tuneup
Fuel Unleaded gasoline with a pump octane
rating of 86 or higher. page 43
Engine Oil SAE 10W-30, API SH or SJ page 33
Spark Plug Type Regular: NGK BP6ES
DENSO W20EP-U
Resistor: NGK BPR6ES
DENSO W20EPR-U
page 36
Maximum Governed
Speed 2,950 ~ 3,100 rpm Shop
manual
Flywheel Brake Cable Adjust for 3/16~3/8 in (5~10) free play at
flywheel brake lever. page 39
Drive Clutch Cable Adjust for 1/16~3/16 in (1~5 mm) free play at
drive clutch lever. page 40
Shift Cable Adjust for proper shift lever operation. page 41
Throttle Cable Adjust for clearance on control arm. page 42
Blade Bolt Torque 36~43 ft-lb (49~59 N•m) page 31
Spark Plug Gap 0.028 ~ 0.031 in (0.7 ~ 0.8 mm) page 36
Idle Speed
(throttle lever at SLOW) 1,700 ± 150 rpm Shop
manual
Valve Clearance (cold) Intake 0.15 ± 0.04 mm
Exhaust: 0.20 ± 0.04 mm
Shop
manual
Other Specifications No other adjustments needed.
