Huffy FR320UKT User Manual

Page 5

background image

5

12/05

ID# M611701

PARTS LIST

Item Qty. Part No.

Description

1

1

206646

Tank (Black)

2

1

200628

Wheel Axle

3

2

226401

Wheel

4

1

908200

Top Pole Section

5

1

908246

Middle Pole Section with Label

6

1

900644

Bottom Pole Section Assembly

7

1

203041

Nut, Hex Flange, 3/8-16

8

1

Net

9

1

201342

Wheel Bracket

10

2

201651

Spacer, Wheel Axle

11

1

902319

Rim Bracket

12

1

206219

Cap

13

1

266001

Bolt, Carriage, 3/8-16 x 1.5 Long

14

1

203617

Tank Cap

15

1

5E2356

Label, Moving System and Height Adjust.

16

3

203084

Bolt, Carriage, 5/16-18 x 1.75 Long

17

5

201344

Knob, Plastic, 3-sided

18

1

Rim

19

2

203053

Bolt, Carriage 5/16-18 x 4

20

1

900253

Backboard Mounting Bracket

21

3

203309

Washer, .406 I.D. x 1.0 O.D.

22

1

Backboard

* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
