14
VOLTAGE SELECTOR SWITCH (DUAL VOLTAGE SYSTEM)
120/240V:
120V ONLY:
VOLTAGE SELECTOR
SWITCH
120/240V
120V
The voltage selector switches the main power carrying windings of the
generator to produce ‘‘120V ONLY’’ or ‘‘120/240V’’. If a 240V appliance
is connected to the 4-prong receptacle, the switch must be in the ‘‘120/
240V’’ position. If only a 120V appliance is being connected to any of
the 120V 3-prong receptacles, select the ‘‘120V ONLY’’ position.
ONLY the 120V receptacles can be used. Do not use the
120/240V receptacle in this position. Rated power will
be available at the 30A 120V locking plug receptacle.
The 120V and 120/240V receptacles can be used
simultaneously.
