T H E C O N T I N U O U S P O W E R C O M P A N Y
Page 13
SPECIFICATIONS
ELECTRICAL
Input CMN3000R/CMN4000R
Voltage 120V +10%, -20% (without
Battery discharge)
Power Factor Corrected IAW MIL STD. 1399 Sec. 300
Frequency 45 to 65Hz
Current(Amps) @ 120VAC 21A/28A @ 100% Non-Linear
Output
Voltage 120VAC
± 3%
Frequency 50Hz / 60Hz (software select)
Line Sync (software select)
Current(Amps) 25A/33A @ 100% Non-Linear
Crest Factor Ratio
(Non-linear load and
less than 5% THD) Typical @50% Load Up to 4.8:1
@75% Load Up to 3.2:1
@100% Load Up to 2.4:1
Total Harmonic Distortion (THD) 3% Typ; 5% Max.
(@100% Non-linear load)
Dynamic Response ±4% for 100% Step Load Change,
0.5 Millisecond Recovery Time
Overload 110% for 10 Minutes;
200% for 50 Milliseconds
Efficiency (UPS) 85-87% Typical
UPS Protection Input and Output Short Circuit;
Input and Output Overload;
Excessive Battery Discharge
ENVIRONMENTAL
Operating Temperature 0 o C to 40 o C
Humidity 0% to 95% Non-condensing
Altitude Sea Level to 10,000 Feet
Audible Noise 42 dBA at Five Feet
MECHANICAL
Input CPC Type 3 Position Inlet
Connectors
Output (Qty.) Load 1 and Load 2 (3 each)
NEMA Type 5-20R
Cooling Low Velocity, Temperature
Controlled Reversible Forced
Air
Dimensions: HxWXD In. 5.25 x 19 x 23
Weight: Lbs. (Kg) 85 (38.8)
DESIGN
Standard Features Power Factor Corrected, Digital
Regenerative
™ On-Line, Sinewave
Inverter Powers Load Continuously
Extended Brownout Protection
Designed for Non-linear Loads
Continuous Operation on
-25%,+12% Line
Automatic Bypass
RS232 Data Interface
Software Selectable Output
Frequency
AC Output Switch
Auxiliary Battery Connector
Rear Mounted Ground Stud
Optional SNMP Interface
Specifications UL 1778, CUL, FCC Class A,
IEEE 587/ANSI C62.41,
IEC 555 @ 120VAC
MTBF In Excess of 100,000 Hours
CONTROLS AND INDICATORS
Visual Indicators
Sequenced LEDs
Single LED
Battery Level, Load Level
AC Input, Inverter On, Load On
Summary Alarm, Alarm Silence,
Cold Start,
Front Panel Controls Power On, Cold Start
Alarm Silence, Battery Test
AC Output On/Off, Bypass
Audible Alarms Utility Interrupt, Inverter Failure
Overload, Low Battery
RS232 Data Interface (DB-9F) Full Interactive, Remote Computer
Monitoring and Control of UPS
Functions.
Compatible with Systems
Enhancement
TM UPS Monitor &
Control Software
Open Collector (DB-9F) Allows Alarm Function Monitoring
Optional SNMP Interface
(RJ45 or BNC)
Allows Full Control and Monitoring
Over Network Connection.
Specifications subject to change without notice
