Holmes HQH307TG - Manual (Page 3)

SETTING THE THERMOSTAT PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance directly
into a 120V AC electrical outlet.
3. The heater is hot when in use. To avoid burns, DO NOT let bare
skin touch hot surfaces. If provided, use handles when moving
this heater. Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, and curtains at least 3 ft (0.9 m) from the
front of the heater and keep them away from the sides and rear.
4. DO NOT run cord under carpeting. DO NOT cover cord with throw
rugs, runners, or the like. Arrange cord away from traffic area
and where it will not be tripped over.
5. This heater is not intended for use in bathrooms, laundry areas
and similar indoor location. NEVER locate heater where it may
fall into a bathtub or other water container.
6. Extreme caution is necessary when any heater is used by,
or near children or invalids, and whenever the heater is left
operating and unattended.
7. Always unplug the heater when not in use.
8. When unplugging, be sure to pull by the plug and not the cord.
9. DO NOT insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock or fire,
or damage the heater.
10.DO NOT operate heater with a damaged cord or plug, or after
the heater malfunctions, has been dropped or damaged in any
manner. Return appliance to manufacturer for examination,
electrical or mechanical adjustment, or repair.
11.A heater has hot and arcing or sparking parts inside.
DO NOT use it in areas where gasoline, paint, or flammable
liquids are used or stored.
12.Use appliance only for intended household use as described
in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or sold
by The Holmes Group may cause hazards.
13.DO NOT use outdoors.
14.To prevent a possible fire, DO NOT block air intakes or exhaust
in any manner. DO NOT use on soft surfaces, like a bed, where
openings may become blocked.
15.To disconnect heater, turn controls to OFF, then remove
plug from outlet.
16.Avoid the use of an extension cord because the extension cord
may overheat and cause a risk of fire. However, if you have
to use an extension cord, the cord shall be No. 14 AWG
minimum size and rated not less than 1875 watts.
17.If the heater will not operate, see specific instructions
on Auto Safety Shut-off.
18. DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your warranty. The inside
of the unit contains no user serviceable parts. All servicing should
be performed by qualified personnel only.
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
1. You need to set thermostat on HI to start heater (See fig. #1
and #2). Allow heater to operate and warm up the room.
2. When the desired temperature/comfort level is reached, lower
the thermostat setting until the fan/heater stops operating.
3. The control will now automatically maintain the pre-set temperature
level by turning the heater ON and OFF.
Note: It is normal for the heater to cycle ON and OFF as it maintains
the preset temperature. To prevent the unit from cycling, you need
to raise the thermostat setting.
THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC
(Alternating Current)PLUG (a plug having one blade wider
than the other). This plug will fit into the power outlet
only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact qualified
personnel to install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY.
PRE-OPERATING INSTRUCTIONS
CLEANING/MAINTENANCE
OPERATING INSTRUCTIONS
1. For heater operation, please set the Thermostat
all the way to HI. (See fig. #1 and #2)
2. Turn the Mode Control to desired heat setting
(LO for 750W or HI for 1500W).
3. The Power Light will remain lit during operation.
During Season Care:
Always unplug the heater, before moving or cleaning.
1. Carefully wipe the unit with a soft, damp cloth. Please
be very cautious near the motor and heating elements.
2. After cleaning, be sure to completely dry the unit
with a cloth or towel.
After Season Care:
1. Store heater in a cool, dry location.
2. Holmes recommends that you store the unit in its original carton.
1. Carefully remove your heater from the box.
(please save the carton for off-season storage).
2. Make sure the unit is in the OFF position before
plugging the heater into the outlet.
3. Avoid overloading your circuit by not using other high
wattage appliances in the same outlet. At 1500 watts,
this unit draws 12.5 amps.
NOTE: This unit is for FLOOR USE ONLY.
ILLUSTRATIONS
TROUBLESHOOTING
If your heater fails to operate:
• Make sure the electrical outlet or circuit breaker is working.
• Check for obstructions. If you find an obstruction turn the heater
OFF, and unplug the unit. Carefully remove the obstruction and
follow the reset instructions.
• The thermostat might be set too low. Turn the thermostat
knob clockwise until the heater restarts.
• Make sure Mode Control is in LO or HI setting.
Please DO NOT attempt to open or repair the heater.
Please see the Warranty for Service Instructions.
AUTO SAFETY SHUT-OFF WITH
INSTANT TIP-OVER PROTECTION:
This heater is equipped with a patented, technologically-advanced safety
system that requires the user to reset the heater if there is a potential
overheat situation. When a potential overheat temperature is reached,
the system will automatically shut the heater off. It can only resume
operation when the user resets the unit.
To Reset the Heater:
1. Turn the Heat Control to the OFF position.
2. Wait 15 minutes for the unit to cool down.
3. Push the reset button on the backside of the unit
and operate normally.
Tip-Over Shut Off:
When the unit is accidentally knocked over, it will instantly
shut off. To reset, simply place the heater in an upright position.
MAXFLOW™ FAN SYSTEM
The patented MaxFlow™ Fan system incorporates a top mounted
fan and internal shroud to provide maximum heat dispersion.
The Maxflow™ Fan system is actived by using the Mode Control
Knob. It delivers a combination of instant, penetrating warmth
in the immediate area, as well as forcing the heat out for entire
room coverage.
Figure 1
Caution Light
Mode Control
Power Light
Reset Button
(not visible)
Thermostat
Figure 2
Caution Light
Mode Control
Power Light
Thermostat
LO 750 Watts
HI 1500 Watts
OFF
