5
02/03 P/N 214960
HARDWARE IDENTIFIER
PARTS LIST
Item #7 (1)
Item #8 (4)
Item #11 (4)*
Item #16 (2)
Item #6 (1)
Item #5 (1)
Item #3 (1)
Item #2 (1)
Item #4 (1)
Item #10 (4)
Item Qty. Part No. Description
1 1 206118 Warning Label
2 1 900033 Slam Jam Bracket, Black
3 1 203796 Bolt, “Tee” 3/8 - NC x 5 Long
4 1 200318 Bracket Reinforcement, Slam Jam
5 1 203472 Spring, Black
6 1 203470 Washer, Flat 5/8 I.D. x 1-1/2 O.D.
7 1 203795 Nut, Special 3/8-NC
8 4 201611 Hex Flange Bolt 5/16-18 x 3 Long
9 1 202795 Logo, NBA
Item Qty. Part No. Description
10 4 203309 Washer, 1 O.D.
11 4* 203100 Hex Flange Nut, 5/16 x 18
12 1 Rim
13 12 201219 Smart Clips, Net Holder
14 1 Net
15 1 200503 Cover, Black
200504 Cover, Red
16 2 200520 Self Tapping Screw, #8 x 1/2
* You may have extra parts with this model.
Item #13 (12)
