LIST PARTS MAINFRAME LOWER
1 FRONT AXLE WELD ASSY 111-0588 1
2 BAR SPRING TENSION 111-0672 1
3 BEARING 6001-2RS 411027 2
4 BEARING FRONT AXLE 410069 2
5 BEARING HOUSING ROLLER 219102 2
6 BELT VARIATOR 536 111-0771 1
7 BOLT CENTRE BBC 343029 1
8 BRACKET CABLE HY412003 1
9 BRACKET CONN ROD 111-0699 1
10 BUSH DIA 6.3*DIA 9.5*7 340154 1
11 BUSH PIVOT 411031 1
12 PULLEY 51MM PCD 111-0634 1
13 CHAIN 40 PITCHES 3/8" INC LINK" 411016 1
14 SUPPORT BRACKET REAR ROLLER 111-0426 1
15 ROD-CONNECTING 111-0202 1
16 COVER DRIVE 411013 1
17 CUTTERBAR BBC 485005 1
18 SPRING CABLE ANCHOR 111-0527 1
19 ROLLER FREEWHEEL ROCKET BRAND 340150 2
20 WARNER BBC 5915-24 485007 1
21 FRONT_FINS 111-0594 1
22 GEARBOX 411002 1
23 GRIP FIX EXT 5/16" 04020 1
24 HOUSING PIVOT BEARING - LH 410048 2
25 CAP HUB 219143 2
26 KEY WOODRUFF No 505 1662 1
27 KNOB HOC 480134 1
28 LEVER HOC 480128 1
29 LEVER VARIABLE PULLEY 411014 1
30 LOCKNUT 340163 1
31 NUT M6 LUG 410076 4
32 MAINFRAME 111-0548-08 1
33 NUT M6 NYLOC 'P' TYPE 09544 2
34 NUT M8 NYL INSERT T TYPE 09441 1
35 NUT UNF 1/2" NYLOC EXT THIN5/16" HY4486 2
36 SPACER NYLON 55*41.5*1 BLACK 340149 1
37 OILITE BUSH ROLLER 340129 2
38 PIN ROLL DIA 3/16*3/4 03997 1
39 PIN SELLOC SPRING 3/16*1 HD HY03354 1
40 PLATE SECURING 219037 1
41 FRAME REAR ROLLER W/A 111-0585-03 1
42 ROLLER SHELL ASSEMBLY 111-0592-03 2
43 SPRING BLADE BRAKE TENSION 343011 1
44 SCREW TAPTITE M6*16 09365 29
45 SCREW TAPTITE M6*16 C/SK POZI 09545 4
46 SCREW TAPTITE M6*20 W/HD 09575 6
47 SCREW TAPTITE M8*25 HEX W/HD 09787 1
48 SETSCREW M6*25 09364 2
1.34
ITEM NO.
QTY.
493 DESCRIPTION PART NO. ITEM NOTE
111-0761(A) 31/3/06 10:46 am Page 1.34
