HOLUX GPSlim240 Wireless Bluetooth GPS Receiver User Guide
8
4.5. Power Supply
z External power source: 5V DC +/- 5%
z Battery:
Main battery: Rechargeable Lithium-ion-ion battery.
Backup battery: Rechargeable 3V Lithium-ion-ion battery for RTC and
satellite data storage.
z Working current: 75-85 mA (under Continuous mode)
z Battery life: Up to 8 hours under full battery and Continuous mode.
4.6. Output Protocol and Interface
z Output Protocol:
I. NMEA 0183 v2.2 protocol
Baud rate: 38400 bps
Data bit: 8
Parity: None
Stop bit: 1
II. Output Format:
9 GPGGA (once per second).
9 GPGSA (once per 5 seconds).
9 GPGSV (once per 5 seconds).
9 GPRMC (once per second).
9 GPVTG (once per second).
9 Choice of GLL or SiRF binary format.
III. Datum: WGS84.
z Input/ Output Interface:
I. Compatible Bluetooth Serial Port Profile (SPP): up to 3 meters
(without obstacles).
II. Output port: Mini USB Type B connector.
III. Choice of compatible accessories
9 1.5 meter USB cable
