Heatilator • ADI60S • 345-900 Rev. G • 9/08
Service Parts
Service Parts Diagram
ADI60S
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM
DESCRIPTION
COMMENTS
PART NUMBER
Log Set Assembly
LOGS-ADI60
Y
1
Log 1
SRV340-701
2
Log 2
SRV340-702
3
Log 3
SRV340-703
4
Log 4
SRV340-704
5
Log 5
SRV340-706
6
Log 6
SRV340-705
7
Log 7
SRV740-707
8
Fireplace Termination Assembly
319-213A
9
Refractory Kit
BRICK-ADI60
10
Burner
349-176A
Y
11
Grate Assembly
327-360A
12
Base Pan
349-124
13
On/Off Rheostat
319-510A
Y
14
Control Panel
319-129
15
Flame Control Knob
571-533
Y
16
Piezo Ignitor
291-513
Y
17
Glass Door Assembly
GLA-349
Y
18
Pilot Control Knob
571-534
Y
19
Rheostat Knob
100-512
Y
20
Blower
GFK-160A
21
Junction Box
040-250A
Y
Flex Pipe Handle
438-351
Glass Latch Assembly
386-122A
Y
Lava Rock
705-420
Mineral Wool
050-721
Pilot Tube
SRV485-301
Y
Thermocouple
2103-511
Y
Thermopile
2103-512
Y
Touch Up Paint
203-9
Conversion Kit NG
NGKS-ADI60
Y
Conversion Kit LP
LPKS-ADI60
Y
Pilot Orifi ce NG
2103-116
Y
Pilot Orifi ce LP
2103-117
Y
Regulator NG
230-1570
Y
Regulator LP
230-1520
Y
Additional service part numbers appear on following page.
