haier ESA405K - Manual (Page 8)

A
B
Top View
Bottom View
Complete Installation
1. Insert the foam seal behind the top of the lower window sash
and against the glass of the upper window.
A. Top of lower window sash
B. Foam seal
Notes
:Push to open the air outlet before using the air conditioner.
Adjust to desired position.
2. Place the window lock bracket as shown. Use a 1⁄8” drill bit to
drill a starter hole through the hole in the window lock bracket
and into the upper window.
3. Attach the window lock bracket to the upper window with one
31⁄32” screw to secure the window in place.
4. Plug into a grounded 3 prong outlet.
5. Press RESET on the power supply cord. See “Electrical
Requirements.”
8
