3 69-0769—1
Fig. 3—Internal schematic for electronic air cleaner with 203365A Conversion Kit.
P3
P4
P1
P2
P17
P18
2
1
P14
P5
P12
3
P21 4
BLACK
1
2
3
4
1
2
3
4
TERMINAL STRIP
FRONT BACK
TO
W8600E
WALL
PANEL
W4 W2 W1 W3
AIR FLOW SWITCH BOARD
ORANGE
GRAY
VIOLET
BLACK
1 INTERLOCK SWITCH.
2 OUTPUT REDUCTION JUMPER.
3 AIRFLOW SWITCH DISABLE JUMPER.
4 RESISTOR FOR W8600 WASH INDICATION THRESHOLD.
5 ONE-CELL UNIT SIMILAR, BUT WITH JUST ONE CELL.
6 POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
M5765A
POWER
SUPPLY
2
5 BLACK
RED
TEST
BUTTON
CONTACT
BOARD
RED IONIZER
BLACK COLLECTOR
BLACK
J2
6
4
R43
BLACK BLACK
BROWN
BLACK
3
1
L1 L2
220/240 VAC
50/60 HZ
BLACK
J7 GREEN
