Huffy 89224 User Manual
Page 6
P/N 211678A
06/03
6
Mount extension arm and
rim to backboard and
finger tighten as shown.
NOTE: For spring
loaded rim assembly,
refer to instructions
included with rim
hardware.
Secure hardware to extension
arm as shown and tighten
completely. Install pole cap (2).
Refer To Combo For
Goal Assembly
Instructions
1.
2.
6
4
5
5
2
7
3
1
