Outdoor Lifestyles by Hearth & Home Technologies Inc. • DSCAR36/42 Doors • 4066-322 • Rev B • 10/09 2
5. Place the hinge on the bottom of left door over the pin
and align hole in hinge to top of pin.
6. Insert door pin into hole of hinge pin provided in fastener
pack and put into hole in upper left firebox top. Push pin
up into hole to allow pin to fit on top of door.
7. Align slot in hinge to the holes in top of door and fasten
with the two screws removed in step 4. Repeat for right
door.
Note: The top hinges will mount to the door the same way
as bottom hinges are mounted.
3. Push one door pin into the hole on the bottom left
side.
4. Remove the two screws in the top of left door.

