Loosely install hardware (2, 3) into holes as shown in Figure B. Attach board pads (4, 5, and 6) with
hardware and tighten completely.
4
5
6
2
3
2
3
FIG. B
ABB. B
2.
FIG. C
ABB. C
6
4
The center board pad is not required if you
have a 44” backboard. Only the left and right
board pads will be used. See figure C.
NOTE:
Part # 205241, # 206292
or #205566 (5) is not used
on 44” acrylic backboards
as shown in Figure C.
NOTE:
