LED Indicators
Description
Power The indicator is lit when the
power is on. Otherwise, it remains
unlit.
Link/Activity These LEDs are lit when there is a
connection (or link) to the desired
port. The LEDs blink whenever
reception or transmission (i.e.,
f data is taking place. Activity) o
Speed These LEDs are Off when there is
(10/100/1000M) a 10Mbps connection (or link) to a
10Mbps Ethernet device at the
associated port; they are lit Green
when there is a 100Mbps
connection (or link) to a 100Mbps
Fast Ethernet device at the
associated port; they are lit Yellow
when there is a 1000Mbps
connection (or link) to a 1000Mbps
Gigabit Ethernet device at the
associated port.
