Thank you for purchasing this Holmes ® product. We
understand the value of quality and are committed to making
superior products that stand the test of time. We trust this
product will exceed your expectations of quality and
reliability. We hope that you enjoy this product and will
consider purchasing another Holmes ® product in the future.
To see our full product line or if you have any questions or
comments about this product, please visit our website at:
www.holmesproducts.com.
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
TECHNICAL SPECIFICATIONS
• Wattage: 1500W (+5% -15%)
• Working voltage: 120V AC/60Hz
AUTO SAFETY SHUT-OFF WITH CERAMIC
CONTROL
This heater is equipped with a patented, technologically
advanced, safety system that requires the user to reset the
heater if there is a potential overheat situation. When a
potential overheat temperature is reached, the system will
automatically shut the heater off. It can only resume
operation when the user resets the unit. For specific reset
instructions please refer to the unit.
Tip-over Shut-off (for HFH111T only):
When the unit is accidentally knocked over, it will shut off.
To reset, simply place the heater in an upright position on a
level surface.
To Reset the Heater (for HFH110 and WF110
only):
1. Turn MODE to OFF.
2. Unplug unit, wait 10 minutes.
3. Plug in again and turn ON.
To Reset the Heater (for HFH111 and HFH111T
only):
If the unit shuts down:
1. Turn MODE to OFF and THERMOSTAT to HI.
2. Unplug unit, wait 10 minutes.
3. Plug in and turn ON.
PRE-OPERATING INSTRUCTIONS
1. Carefully remove your heater from the box. Please save
the carton for off-season storage.
2: Make sure the unit is in the OFF position before
plugging the heater into the outlet.
3. Place heater on firm level surface.
4. Avoid overloading your circuit by not using other high
wattage appliances in the same outlet.
OPERATING INSTRUCTIONS
1. Turn the Selector Control to desired heat setting LO or
HI.
2. For fan-only operation, without any heat output, turn
the Selector Control to the FAN setting.
3. The Power Light will remain lit during operation.
SETTING THE THERMOSTAT (FOR HFH111
AND HFH111T ONLY)
1. You need to set thermostat on HI to start heater (See
fig. #1). Allow heater to operate and warm up the
room.
2. When the desired temperature/comfort level is
reached, lower the thermostat setting until the
fan/heater stops operating.
3. The control will now automatically maintain the pre-set
temperature level by turning the heater ON and OFF.
NOTE: It is normal for the heater to cycle ON and OFF as it
maintains the preset temperature. To prevent the unit from
cycling, you need to raise the thermostat setting.
P L E A S E R E A D A N D S AV E T H E S E
I M P O R TA N T S A F E T Y I N S T R U C T I O N S
F E AT U R E S - O P E R AT I O N S
When using electrical appliances, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock, and injury to
persons, including the following:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance
directly into a 120V AC electrical outlet.
3. The heater is hot when in use. To avoid burns, DO NOT
let bare skin touch hot surfaces. If provided, use handles
when moving this heater. Keep combustible materials,
such as furniture, pillows, bedding, papers, clothes, and
curtains at least 3 ft (0.9 m) from the front of the heater
and keep them away from the sides and rear.
4. DO NOT run cord under carpeting. DO NOT cover cord
with throw rugs, runners, or the like. Arrange cord away
from traffic area and where it will not be tripped over.
5. This heater is not intended for use in bathrooms,
laundry areas and similar indoor location. NEVER locate
heater where it may fall into a bathtub or other water
container.
6. Extreme caution is necessary when any heater is used
by, or near children or invalids, and whenever the
heater is left operating and unattended.
7. Always unplug the heater when not in use.
8. When unplugging, be sure to pull by the plug and not
the cord.
9. DO NOT insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
10. DO NOT operate heater with a damaged cord or plug, or
after the heater malfunctions, has been dropped or
damaged in any manner. Return appliance to
manufacturer for examination, electrical or mechanical
adjustment, or repair.
11. A heater has hot and arcing or sparking parts inside. DO
NOT use it in areas where gasoline, paint, or flammable
liquids are used or stored.
12. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by The Holmes
Group may cause hazards.
13. DO NOT use outdoors.
14. To prevent a possible fire, DO NOT block air intakes or
exhaust in any manner. DO NOT use on soft surfaces,
like a bed, where openings may become blocked.
15. To disconnect heater, turn controls to OFF, then remove
plug from outlet.
16. Avoid the use of an extension cord because the
extension cord may overheat and cause a risk of fire.
However, if you have to use an extension cord, the cord
shall be No. 14 AWG minimum size and rated not less
than 1875 watts.
17. If the heater will not operate, see specific instructions on
Auto Safety Shut-off.
18. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user
serviceable parts. All servicing should be performed by
qualified personnel only.
19. Discontinue use if plug or outlet is hot. It is
recommended that the outlet be replaced if plug or
outlet is hot to touch.
CLEANING/MAINTENANCE
• Always unplug the heater before cleaning.
• Lightly run a vacuum cleaner nozzle over the heater
grill to remove any dust or dirt that may have
accumulated.
• Carefully wipe the heater with a soft, damp cloth. Please
be very cautious near the motor and heating elements.
• NEVER use abrasive or flammable solvents to clean the
heater.
• After cleaning, be sure to completely dry the heater with
a cloth or towel.
• Store your heater in its original carton in a cool, dry
location.
TROUBLESHOOTING
If your heater fails to operate, unplug the
heater and:
• Make sure the electrical outlet and circuit breaker are
working.
• Check for obstructions. If you find an obstruction, turn
OFF and UNPLUG the heater. Carefully remove the
obstruction and follow the reset instructions.
• Check the thermostat setting; it might be set too low.
Turn the thermostat dial clockwise until the heater
restarts.
• Make sure the Mode Control is in Lo or Hi setting.
Please DO NOT attempt to open or repair the heater.
Please see the Warranty for Service Instructions or
call our Consumer Services Department at 1-800-5-
HOLMES.
ILLUSTRATIONS
F E AT U R E S - O P E R AT I O N S
THIS PRODUCT IS EQUIPPED WITH A POLARIZED PLUG (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug. If it still does not fit, contact qualified personnel
to install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY
A. Carry Handle (not
shown)
B. Selector Control
C. Power Light
Figure 1
C
B
A
for HFH110 & WF110
Figure 2
for HFH111 & HFH111T
A. Power Light
B. Mode Control
C. Thermostat Control
D. Carry Handle (not
shown)
C D B
A
