Characteristic of the burners and nozzles
Table 1
Liquid Gas
Natural Gas
Burner
Diameter
(mm)
Thermal power
kW (p.c.s.*)
By-Pass
1/100
Nozzle
1/100
Flow*
g/h
Nozzle
1/100
Flow*
l/h
Nomin.
Ridot.
(mm)
(mm)
***
**
(mm)
Fast (R)
100
3,00
0,70
41
86
218
214
116
286
Reduced Fast
(RR)
100
2,60
0,70
41
80
189
186
110
248
Semi Fast (S)
75
1,90
0,40
30
70
138
136
106
181
Auxiliary (A)
55
1,00
0,40
30
50
73
71
79
95
Triple Crown
(TC)
130
3,60
1,30
57
94
262
257
137
343
Ultrarapid (UR)
100
3,40
0,70
41
91
240
236
123
314
Fishburner (P)
—
3,00
1,30
63
86
218
214
116
286
Semi-Fishburner
(SP)
—
1,50
0,70
41
60
109
107
88
143
Double flame
(DCDR internal)
30
0,90
0,40
30
44
65
64
70
86
Double flame
(DCDR external)
2 nozzle
130
4,10
1,30
57
70
298
293
114
390
Supply
Pressures
Nominal (mbar)
Minimum (mbar)
Maximum (mbar)
28-30
20
35
37
25
45
20
17
25
*
At 15°C and 1013 mbar-dry gas
**
Propane P.C.S. = 50.37 MJ/kg.
***
Butane P.C.S. = 49.47 MJ/kg.
Natural P.C.S. = 37.78 MJ/m
3
Rapid
Reduced Rapid
Semi Rapid (S)
