Page 2 For technical questions, please call 1‑800‑444‑3353. SKU 44599
Specifications
Max. Weight
Capacity
200 lb.
Dimensions
44” H x 30” L x 27‑
1/2” W (at wheels)
Important Safety Information
1. Do not exceed 200 lb. max
weight capacity. Be aware of
dynamic loading! Sudden load
movement may briefly create excess
load causing product failure.
2. Wear ANSI‑approved safety
goggles and heavy‑duty work
gloves during assembly. Wear
gloves when stacking firewood.
3. Use as intended only. Do
not use Cart to transport any
items other than firewood.
4. Inspect before use; do not use
if parts loose or damaged.
5. Not a toy; keep away from children.
6. Keep assembly area clean and well lit.
Cluttered or dark areas invite accidents.
7. Stay alert, watch what you are
doing and use common sense when
using this product. Do not use this
product while you are tired or under
the influence of drugs, alcohol or
medication. A moment of inattention
while using this product may result
in serious personal injury.
8. Do not overreach. Keep proper
footing and balance at all times.
This enables better control of this
product in unexpected situations.
9. Store this product out of the reach
of children and do not allow people
unfamiliar with the product or these
instructions to operate the product.
10. Maintain this product. Check for
misalignment or binding of parts,
breakage of parts and any other
condition that may affect the
product’s operation. If damaged,
have this product repaired before
use. Many accidents are caused
by poorly maintained equipment.
11. Maintain labels and nameplates
on the Inner Tie Rod Tool. These
carry important safety information. If
unreadable or missing, contact Harbor
Freight Tools for a replacement.
12. The warnings, precautions, and
instructions discussed in this instruction
manual cannot cover all possible
conditions and situations that may
occur. It must be understood by the
operator that common sense and
caution are factors which cannot
be built into this product, but must
be supplied by the operator.
Assembly
1. Position the U‑Handle (1) inside the
grooves of the Base Frame (4). Attach
the U‑Handle to the Base Frame
using the Bolts (10) on each side of
the U‑Handle. Fasten together using
the Washer (14) and Nuts (13).
2. Position the Left Frame (7) inside the
left groove of the Base Frame opposite
the end with the U‑Handle attached.
Secure Left Frame with Nuts and Bolts
and repeat for the Right Frame (8).
3. Attach Bracket (9) to the Left
and Right Frame pieces using
remaining Nuts and Bolts. NOTE:
Be sure the folded edge of Bracket
points in towards the U‑Handle.
