Page 10
10
Physical Data
Model RLC
Air Defrost
Model
No. of
Fans
Connections (in.)
Approx. Net
Wt.
Coil Inlet
OD
Suction ID
External
Equalizer OD
Drain MPT
lbs.
kg
RLC040
1
1/2
5/8
1/4
3/4
28
13
RLC052
1
1/2
5/8
1/4
3/4
31
15
RLC065
1
1/2
7/8
1/4
3/4
34
16
RLC070
2
1/2
7/8
1/4
3/4
45
21
RLC090
2
1/2
7/8
1/4
3/4
48
22
RLC104
2
1/2
7/8
1/4
3/4
49
23
RLC120
2
1/2
7/8
1/4
3/4
51
24
RLC130
2
1/2
7/8
1/4
3/4
53
25
RLC140
3
1/2
7/8
1/4
3/4
63
29
RLC156
3
1/2
7/8
1/4
3/4
67
31
RLC180
3
1/2
7/8
1/4
3/4
69
32
RLC208
4
1/2
1-1/8
1/4
3/4
82
38
RLC260
5
1/2
1-1/8
1/4
3/4
103
47
RLC312
6
1/2
1-1/8
1/4
3/4
124
57
RLC370
6
1/2
1-3/8
1/4
3/4
127
58
Model ELC/EFC
Electric Defrost
Model
No. of
Fans
Connections (in.)
Approx. Net
Wt.
Coil Inlet
OD
Suction ID
External
Equalizer OD
Drain MPT
lbs.
kg
6 F
ins P
er I
nch
ELC035
1
1/2
5/8
1/4
3/4
24
11
ELC040
1
1/2
5/8
1/4
3/4
26
12
ELC047
1
1/2
5/8
1/4
3/4
29
14
ELC065
2
1/2
5/8
1/4
3/4
43
20
ELC075
2
1/2
5/8
1/4
3/4
45
21
ELC090
2
1/2
7/8
1/4
3/4
48
22
ELC120
3
1/2
7/8
1/4
3/4
60
28
ELC140
3
1/2
7/8
1/4
3/4
62
29
ELC160
4
1/2
1-1/8
1/4
3/4
81
37
ELC180
4
1/2
1-1/8
1/4
3/4
84
39
ELC200
5
1/2
1-1/8
1/4
3/4
101
46
ELC240
6
1/2
1-1/8
1/4
3/4
121
55
ELC280
6
1/2
1-1/8
1/4
3/4
124
57
4 F
ins P
er I
nch
EFC041
1
1/2
5/8
1/4
3/4
28
13
EFC068
2
1/2
7/8
1/4
3/4
44
21
EFC080
2
1/2
7/8
1/4
3/4
47
22
EFC102
3
1/2
7/8
1/4
3/4
59
27
EFC136
4
1/2
1-1/8
1/4
3/4
80
37
EFC170
5
1/2
1-1/8
1/4
3/4
100
46
EFC204
6
1/2
1-1/8
1/4
3/4
120
55
EFC235
6
1/2
1-1/8
1/4
3/4
123
56
