3
Install the Wallbar
Tools Required (not included): a) adjustable wrench, b) drill with 1/4" (6.4 mm) bit
suitable for the wall surface, c) Philips head screwdriver, d) silicon sealant, e)
plumbers’ thread tape (i.e. Teflon TM tape)
• Remove decorative screw covers from wall bar end
pieces. Position bar so hand shower may be adjusted at
a convenient height for intended users. Mark location of
mounting holes. Put wall bar in a safe location. CAU-
TION: Do not install wall bar directly between shower
arm and valve. A water line may be located there and
may be damaged while drilling mounting holes.
• Drill holes through shower wall.
Install anchors. Seal wall around the
anchors with silicon sealant.
• Attach wall bar to wall using screws and metal washers
provided.
• Reinstall decorative screw covers.
