Huffy 8000 - Manual (Page 3)

3 05/05 ID# M800004
PARTS LIST - See Hardware Identifier
Item Qty. Part No. Description
1 1 206118 Warning Label
2 4 203113 Bolt, Hex Flange, 5/16-18 x 2.5 Long
3 2 203038 Bolt, Carriage, 5/16-18 x 2.75 Long
4 6 203309 Washer, 1” O.D.
5 6* 203100 Nut, Hex Flange, 5/16-18
6 1 Rim
7 1 Net
8 1 Backboard
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
#2 (4)
#5 (6)*
#4 (6)
#3 (2)
HARDWARE IDENTIFIER
#6 (1)
#8 (1)
#7 (1)
WARNING
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT
IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
Owner must ensure that all players know and
follow these rules for safe operation of the unit.
In the U.S.: 1-800-558-5234 and Canada Only: 1-800-284-8339 In Australia: 1-800-632-792 206118 5/97
See instruction manual for proper installation and
maintenance.
Use caution when performing dunk type activities on this unit.
Do not hang from any part of unit, including backboard,
support braces, rim or net.
Check unit before each use for loose hardware, excessive
wear and signs of corrosion and repair before using.
During play, use extreme caution to keep player's face away
from the backboard, rim or net. Serious injury could occur if
teeth/face come in contact with backboard, rim or net.
During play, do not wear jewelry (rings, watches, necklaces,
etc.) Objects may entangle in net.
·
·
·
·
·
·
#1 (1)
