HEIGHT AND MOVING LABEL
MUST NOT OBSTRUCT
FACTORY ATTACHED
WARNING LABEL.
200439 11/00
1
3 2
MOVING SYSTEM
1. While holding pole, rotate basketball system forward
until wheels engage with
ground.
2. Move basketball system to desired location.
3. Carefully rotate basketball system upright.
4. Reattach ground restraint and check system for stability.
HEIGHT ADJUSTMENT
A
WARNING
Backboard may rotate during
height adjustment.
B
WARNING
Do not adjust height of system
in upright position. System must
be in down position to adjust
Rest unit on support table. Remove adjustment knobs (A)
and carriage bolts (B) to extend or retract backboard and rim.
Height adjustment from 7
1/2 ' to 10'.
SAND
360 LBS.
(163 KG)
CAUTION!
DO NOT LEAVE
ASSEMBLY UNATTENDED
WHEN EMPTY; IT MAY TIP
OVER.
WARNING!
