109632 09/08 3-3
Gauge Arm Assembly—549196
NOTES:
1. Apply grease to zerks.
2. Do not fully spread Item 11 (017277 Cotter Pin) for quicker adjustment
of washers.
3. Tighten Item 21 (061101 Nut), then back off until wheel spins freely.
4. Assemble Item 4 (784223 Bearing) with inner races toward Item 14
(310185 Spacer).
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 705954 705954 1 CS .500-13X1.25 HX G5 Z
2 344267 344267 1 FW .510X 2.15X.187 SPL
3 798603 798603 1 FW .515X1.65X.125 HD ZY
4 784223 784223 2 BEARING
5 017350 017350 1 SS .250-20X .250 SH BO
6 466698 466698 1 HANDLE GAUGE WHEEL ARM
7 068759 068759 15 CW .560X 1.340X .05 PN
8 315234 315234 1 LINKAGE PIN
9 466680 466680 1 LOCK LINKAGE
10 466672 466672 1 LOCK PIN GAUGE WHEEL ARM
11 017277 017277 1 CP .187DX1.000 LG HML Z
12 315226 315226 1 HANDLE PIN
13 345652 345652 1 GAGE WHEEL ARM
14 310185 310185 1 SPACER 1.07X1.312X1.29
15 469924 469924 1 GAGE WHEEL SPACER 1/4"
16 469882 469882 2 GAGE WHEEL SPACER 1/2"
17 786731 786731 1 CS .750-10X8.00 HX GR5
18 025296 025296 2 FW .760X 1.625X.08 ZNYC
19 109478 109478 1 FORK W/A 13 X 5.0 TIRE
20 786061 786061 1 WHEEL/TIRE ASSY 13X5.00
21 061101 061101 1 NT .750-10 HXZY NL
