HoMedics DocknParty DP-300 - Manual (Page 5)

Listening to a non-docking iPod or other
portable audio devices
If you are using an iPod without a docking port, other MP3 player, or other
portable audio device, you can play it through the Dock n Party via
the LINE IN jack located on the back of the unit. (Fig. 5)
1. Plug one end of the Connection Cable (included) (Fig. 1) into the head-
phone or line-out jack on your audio device and the other end of the
Connection Cable into the Dock n Party LINE IN jack located on the back of
the unit (Fig. 5).
2. Press the POWER button on the unit to turn it on (Fig. 3).
3. Turn on and play external audio device.
4. Press the ‘+’ or ‘-’ button on the Dock n Party unit to adjust volume (Fig. 1).
Note: You may need to adjust the volume on external device too.
5. To turn unit off, press the POWER button on the back of the unit.
Note: You also need to turn off your external audio device as well.
DC IN LINE IN POWER
DC IN LINE IN POWER
Figure 5
iPod ® Shuffle
Connection
Cable
Aux
8 9
Changing the Colored Faceplates
Attaching Faceplate
1. Choose a faceplate.
2. Gently place faceplate on top of Dock n Party unit, with two button holes
placed above the ‘+’ and ‘-’ buttons.
3. (a) Press down on rear of faceplate to lock back two tabs. (b) Then press
down on front of faceplate to lock front two tabs. (Fig. 6) Be sure all 4 tabs
are securely locked in place.
Removing Faceplate
1. With one hand on each side of unit, firmly press up on the two front tabs of
the faceplate, until the front of the faceplate is raised off unit. (Fig. 7)
2. Grasp front of faceplate, pulling up and gently loosening all four locking
tabs. Be sure not to force or pull too hard, so the tabs do not break.
3. See ATTACHING FACEPLATE for directions on replacing the faceplate.
(a)
(b)
Figure 6 Figure 7
