5
How To Use Your Hob
Know your Hob
To turn on a cooking area and increase its power
level, select the desired cooking area. Then turn the
corresponding control to the required position. The higher the
number, the greater the power.
To turn off the cooking area, return the control to 0 and
the cooking area is turned off.
Pilot lights (A and B)
When pilot lights are lit they indicate:
A - one or more of the cooking areas are switched on.
B - The ceramic surface is hot (in excess of 50°C).
Even after a cooking area is turned off some types of pilot
light stay on to show that the corresponding cooking area is
still hot. These pilot lights warn you there is still the risk of
injury by burning.
A
A
A
A
C Cooking areas
1 and 2
Controls
A and B Pilot lights
Switch Energy Regulator Heat
1 1 - 2 Least Hot
2 3 - 4
3 5 - 6
4 7 - 8
5 9 - 10
6 11 - 12 Hottest
