Front Panel Control
Control Panel Function
1. Standby switch
2. SOURCE Call the Input Source menu/Confirm button when operation
menu.
3. MENU Press to select the main menu
4. VOL- Volume down / Left orientation to adjust the item in the OSD
VOL+ Volume up / Right orientation to adjust the item/Press to enter
5. CH- TV channel down / to select the item in the menu
CH+ TV channel up / to select the item in the menu
6. Power indicator
7.Remote Sensor
6
7
SOURCE MENU VOL- VOL+ CH- CH+ POWER
2 3 4 5 1
SOURCE MENU VOL- VOL+ CH- CH+ STANDBY
(The figure above and the description of the button may be different,
all picture in this manual is just for reference, please see the actual set.)
6
7
12W
11W
T1
SOURCE MENU VOL- VOL+ CH- CH+ STANDBY
2 3 4 5 1
R1
S
O
U
R
C
E
Or
POWER
