SKU 95409
For technical questions, please call 1-800-444-3353.
partS liSt
part
Description
Q’ty
Caster Assembly
4
2
Left Main Beam
3
Flat Washer M2
8
4
Lock Washer M2
8
part
Description
Q’ty
5
Nut M2
8
6
Bolt M2 X 30 (-/4” long)
4
7
Cross Beam
8
Right Main Beam
pleaSe reaD the FolloWing careFully
THe MANUFACTUReR AND/OR DISTRIBUTOR HAS PROvIDeD THe PARTS LIST AND
ASSeMBLY DIAGRAM IN THIS MANUAL AS A ReFeReNCe TOOL ONLY. NeITHeR THe
MANUFACTUReR OR DISTRIBUTOR MAKeS ANY RePReSeNTATION OR WARRANTY OF
ANY KIND TO THe BUYeR THAT He OR SHe IS qUALIFIeD TO MAKe ANY RePAIRS TO THe
PRODUCT, OR THAT He OR SHe IS qUALIFIeD TO RePLACe ANY PARTS OF THe PROD-
UCT. IN FACT, THe MANUFACTUReR AND/OR DISTRIBUTOR eXPReSSLY STATeS THAT
ALL RePAIRS AND PARTS RePLACeMeNTS SHOULD Be UNDeRTAKeN BY CeRTIFIeD AND
LICeNSeD TeCHNICIANS, AND NOT BY THe BUYeR. THe BUYeR ASSUMeS ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HeR RePAIRS TO THe ORIGINAL PRODUCT OR
RePLACeMeNT PARTS THeReTO, OR ARISING OUT OF HIS OR HeR INSTALLATION OF
RePLACeMeNT PARTS THeReTO.
operation
Place one Wheel Dolly (sku 94682, sold separately) on each of the four hold-
ers on the Cross Beam (7). The metal part of each dolly should slide over one
holder.
Store stand and dollies in a dry, level place where they will not present a tripping
hazard.
.
2.
