HOLUX
8
3. After the installation is complete, go to and select to verify if a
virtual COM port was created.
4.3 Important
Verify the COM port # to start using your own navigating software.
1. Click menu, select , then enter <Control Panel>.
2. After entering , select .
3. Select .
4. Find the and check the Virtual COM Port, which was created by the USB driver,
Please note that the Virtual COM Port number might be different from every computer. Before using
navigating software, please confirm the COM Port numbers created by your computer and provided by
your navigation software. Otherwise, the navigating software won’t receive the satellite signal, because of
the un-match COM Port setting.
5. Software Interface
The GM-210 interface protocol is based on the National Marine Electronics Association's NMEA 0183 ASC
Ⅱ interface specification, which is defined in NMEA 0183, Version 2.2 and the Radio Technical Commission for
Maritime Services (RTCM Recommended Standards For Differential Navstar GPS Service, Version 2.1, RTCM
Special Committee No.104, Type 1,2,9) or WAAS (in USA area) or EGNOS (in European area)
).
5.1 NMEA Transmitted Messages
The GM-210 supported by SiRF Technology Inc. also outputs data in NMEA-0183 format as defined by the
National Marine Electronics Association (NMEA), Standard.
The default communication parameters for NMEA output are 4800 baud, 8 data bits, stop bit, and no parity.
Table 5-1 NMEA-0183 Output Messages
NMEA Record Description
GPGGA Global positioning system fixed data
GPGLL Geographic position- latitude/longitude
GPGSA GNSS DOP and active satellites
GPGSV GNSS satellites in view
GPRMC Recommended minimum specific GNSS data
GPVTG Course over ground and ground speed
5.1.1 Global Positioning System Fix Data (GGA)
Table 5-2 contains the values for the following example:
$GPGGA,161229.487,3723.2475,N,12158.3416,W,1,07,1.0,9.0,M, , , ,0000*18
Table 5-2 GGA Data Format
Name Example Units Description
Message ID $GPGGA GGA protocol header
UTC Time 161229.487 hhmmss.sss
Latitude 3723.2475 ddmm.mmmm
N/S Indicator N N=north or S=south
Longitude 12158.3416 dddmm.mmmm
E/W Indicator W E=east or W=west
Position Fix Indicator 1 See Table 5-3
Satellites Used 07 Range 0 to 12
