SECTION VI –
MISCELLANEOUS CHARTS AND FORMULAS
ELEMENT CHART
Power (kW)
Resistance (Ohms)
Element
Part #
208V 240V 480V
Immersion
Length
Hairpin
1
Φ
3
Φ DELTA 3 Φ WYE
50-38683SSN 5 6 8
13"
27.9
9.3
27.9
18.7
60-38683SSN 6 8 10
13"
21.6
7.2
21.6
14.5
70-38683SSN 8 10 12
13"
17.1
5.7
17.1
11.5
80-38683SSN
10
12 15 13"
14.4 4.8
14.4
9.6
90-38683SSN 12 15 20
15"
12.1
4.0
12.1
8.1
100-38683SSN 15
20 ---- 15"
9.1
3.0
9.1
6.1
110-38683SSN 17.3 ---- ----
15"
7.5
2.5
7.5
5.0
FORMULAS
