Parts List
The following replacement parts for your Harman Clarity Fireplace Insert are available from your Har-
man dealer.
1. Pilot
NG
3-40-08229
Pilot
LP
3-40-08230
2. Thermopile
3-20-08219
3. Pilot Tube
2-00-446118
4. Thermocouple
3-40-08228
5. Piezo Ignitor
3-40-08220
6. Ignitor Cable
3-40-08231
7. Pilot Bracket
2-00-446134
8. Tube Box Top
2-00-446110
9. Rear Orifice(NG) #44
3-40-25844
Rear Orifice (LP) #55
3-40-25855
10. Center Orifice (NG) #56 3-40-57356
Center Orifice (LP) #71
3-40-57271
11. Front Orifice (NG) #47
3-40-25847
Front Orifice (LP) #57
3-40-25857
12. Divider Plates (2)
2-00-446108
13. Burner Weldment
1-10-08575
14. Air Dam
2-00-446132
15. Valve Heat Shield
2-00-446135
16. Valve (NG)
3-40-820628
Valve (LP)
3-40-82057
17. Valve Door Magnet
3-31-08225
18. 3/8 pipe x 3/8 comp. L
3-31-08567
19. L Tube
2-00-08586
20. 3/8 pipe x 3/8 comp.
3-31-08284
21. 1/4 pipe x 3/8 comp. L
3-31-08566
22. S Tube Flex
3-40-8618
23. Label
24. Rear Air Adjuster
2-00-446113
25. Center Air Adjuster
2-00-446112
26. Front Air Adjuster
2-00-446111
27. Front Burner Tube
3-40-08224
28. Center Burner Tube
3-40-08225
29. Rear Burner Tube
3-40-08226
30. Burner Plate
1-10-08577
31. 1/4-20x5/8 Self Tap
3-30-1252006216
32. Burner Retainer
2-00-4211
33. 1/4-20x1 bolt
3-30-1252010013
34. Air Deflector
1-10-08576
35. Door (without frame)
1-10-08587
Arch Frame
1-00-446303
Sunrise Frame
1-00-446304
36. Burner Module (NG)
1-10-08700
Burner Module (LP)
1-10-08800
37. Gold Bars (2)
4-40-00141
Bar Holders (Left)
2-00-446300-1
Bar Holder (Right)
2-00-446300-2
38. Retainer Clips (2)
2-00-446322
39. Blower Assembly
1-10-08594
40. Valve Door
1-00-08592
41. U Bolt
3-31-08568
42. Pipe Nipple 13 1/2"
3-50-08570
43. 1/4 pipe x 3/8 comp. L
3-31-08566
44. 1/4" Coupling
3-10-3001025
45. Air Inlet Grill
1-10-08593
46. Latch Plate (2)
2-00-446315
47. Right wing
2-00-446313
48. Right Wing Cover
1-10-08593
49. Right Wing Bracket
2-00-446306
50. Flue Switch Bracket
2-00-446326
51. Stove Body Weldment
1-89-08700
52. Insulation
3-44-08562
53. Stove Top
1-10-08595
54. Draft Tube
2-00-446327
55. Draft Hood Weldment
1-10-08579
56. Vent Flange (std.)
1-10-08591
57. Flue Adaptor (optional) 1-10-08601
58. Top Wing
2-00-446312
59. Top Wing Cover
2-00-446308
60. Left Wing Bracket
2-00-446307
61. Left Wing Cover
2-00-446309
62. Left Wing
2-00-446311
63. Side Cover
1-10-08593
64. Hood Retainer
1-10-08590
65. Base
2-00446323
