Optional Steam Package
10
Please Complete The Following Information:
Tube Sheet Data
Outside Diameter
Thickness
Material
Number of Tube holes
in the tube sheet
Does the tube sheet have
Bolt Holes in it?
Yes No
If Yes:
■ # of bolt holes
■ Dia. of bolt holes
■ Bolt circle
Do the bolt holes straddle
the centerline?
Yes No
Diameter of the neck nozzle on the tank.
Outside Diameter
Inside Diameter
(Include thickness of neck lining, if any)
Circumference Of Neck
Immersion length
of tubes “B”
Heating surface area
in Sq. Ft. (if known)
Tank Type: Vertical Horizontal
Tank dimensions: Diameter
Height
Pull space
maximum length
3
2
Tube Outside
Diameter
Material
Gauge BWG
Type Single Wall Double Wall
Design Pressure
Design Temperature
Number of passes
Number of tube
supports
Full Half type
Distance to each
tube support
Material
O.D. of supports
Thickness
Recovery rated
to heat GPH
from o F to o F
When supplied with the following
heat source:
Steam at
psig
Lbs. / Hour
Steam Consumption
Boiler Water at GPM
from o F to o F
HTHW at GPM
from o F to o F
Pressure Drop
Steam psi
Boiler or HTHW psi
1
7
6
5
4
8
Heating Coil General Configuration
Rib Gasket
Length B
Tube Support Tubes
Inlet
Outlet
Head Tube
Sheet
Tank
Flange
Tank Tank Lining Ring Gasket
