2 To disconnect the handgrip from the tube, hold the standard handgrip with one hand. With
the other hand, hold the telescopic tube with or without PostureProtect handgrip (specific
types only), press the tube release button (1) and pull the tube off the handgrip (Fig. 10).
Note: This vacuum cleaner has been fitted with holes (specific types only) at the end of the handgrip.
These holes may prevent objects from getting stuck or damaged when you use your vacuum cleaner
without the tube or accessories supplied.
hose
1 To connect the hose, push it firmly into the appliance (‘click’) (Fig. 11).
2 To disconnect the hose, press the release button (1) and pull the hose out of the appliance
(2) (Fig. 12).
telescopic tube
1 Adjust the length of the tube in such a way that the hand holding the standard handgrip is at
hip level (Fig. 13).
2 Hold the tube so that the standard handgrip is at hip level. (Fig. 7)
3 To connect the tube to a nozzle, press the spring-loaded lock button on the tube and insert
the tube into the nozzle. Fit the spring-loaded lock button into the opening in the nozzle
(‘click’) (Fig. 14).
accessory holder
1 Slide the accessory holder onto the handgrip (‘click’) (Fig. 15).
2 Push the accessories onto the holder. (Fig. 16)
3 To detach the accessory holder, squeeze the release levers together (1) and slide the
accessory holder off the handgrip (2) (Fig. 17).
Crevice tool, small nozzle and brush attachment
1 Connect the crevice tool (1) or small nozzle (2) with or without brush attachment directly
to the standard handgrip or to the tube (Fig. 18).
Brush attachment
1 To assemble the brush attachment, slide it onto the bottom of the small nozzle
(‘click’) (Fig. 19).
2 To disassemble the brush attachment, slide it off the bottom of the small nozzle (Fig. 20).
tri-active nozzle (specific types only)
The Tri-Active nozzle is a multi-purpose nozzle for carpets and hard floors.
- The side brushes catch more dust and dirt at the sides of the nozzle and allow you to clean
better along furniture and other obstacles (Fig. 21).
- The opening at the front of the nozzle allows you to suck up larger particles (Fig. 22).
1 Use the hard floor setting to clean hard floors (for instance for tiled, parqueted, laminated
and linoleumed flooring): push the rocker switch on top of the nozzle with your foot to
make the brush strip come out of the housing. At the same time, the wheel is lifted to
prevent scratching and to increase manoeuvrability (Fig. 23).
2 Use the carpet setting to clean carpets: push the rocker switch again to make the brush strip
disappear into the nozzle housing. The wheel is lowered automatically (Fig. 24).
