haier XPB58-113S - Manual (Page 10)

8
Washing sequence
Figure 1
Spin timer
Wash timer
Wash selector
(To set to below 2 minute,
first set to 5 minute then
turn it back. it can increase
the service life of the timer).
(standard current,
strong current)
(to set to below 1 minute,
first set to 2 minute then
turn it back. it can increase
the service life of the timer).
Wash
Figure 3
Figure 2
WASH SELECTOR
1. Fill the water and add the dissolved washing
powder to make the water level reach the preset
position. (Figure 1)
Run washing program for some time to stir and
dissolve the powder completely.
2.Put in the laundries. If the water quantity is
insufficient, please add water.
3.Select the current.
Select the strength of the current according to
the laundries. (Figure 2
4.Select the washing time
Select the washing time according to the
laundries. (Figure 3)
5.After washing, the buzzer will ring. Set the "WASH
SELECTOR" at "DRAIN". (Figure4).
WASH TIMER
STANDARD
STRONG
OFF
1
2
3
4
5 DRAIN
WASH SELECTOR
SPIN TIMER
12
9
6 3 OFF
SOAK
15
45
35
25
WASH
DRAIN
STRONG
STANDARD
WASH TIMER
12
9
6
3
OFF
SOAK
15
45
35
25
WASH
Figure 4
DRAIN
WASH SELECTOR
STANDARD
STRONG
Spin water-filling entrance
Spin water-filling entrance
Remarks:
a. 0~15 minute is the normal soaking.
b. 15~45 minute is active soaking. During active soaking,
the pulsator will run for 2 minutes in each 8 minutes. After
the active soaking, it will run normal washing for 15 minutes.
C . If you select soaking(i.e. turn the knob to position between
15~45 minutes), be sure to
dissolve the washing powder in advance, otherwise the
washing powder may result in damage to the laundries.
