4
Outdoor Unit With This Indoor Air handler
Model Number
HC18C1VAR HB2400VC1M20
HC24C1VAR HB2400VC1M20
HC30C1VAR HB3600VA1M20
HC36C1VAR HB3600VC1M25
HC42C1VAR HB4800VA1M25
HC48C1VAR HB4800VA1M25
HC60C1VAR HB6000VC1M25
41800 2900 58000 12 Bristol
Table 4:System Cooling Capacity
Air Handler Cooling Capacity (Btu/h) SEER Rated
Sensible Total CFM(Outdoor)
14820
18720
23400
25920
1950
1950
1950
2700 19000
24000
30000
36000
12
12
12
12
30240
34560 2900
2900 42000
48000 12
12
Compressor
brand
Bristol
Bristol
Bristol
Bristol
Bristol
Bristol
15 20 20 25 30 35 55
Rated Load Amps 6.2 8.6 9.2 11.7 13.0 15.8 25.0
Compressor Locked Running
Amps 41 60 60 73 85 90 150
Full Load Amps 0.86 0.86 0.86 1.3 1.43 2.0 2.0
Fan Motor Rated HP 1/8 1/6 1/6 1/4 1/3 1/3 1/3
Nominal RPM 1000 840 840 850 1075 960 880
Liquid Line OD - In (mm) 3/8"[9.52] 3/8"[9.52] 3/8"[9.52] 3/8"[9.52] 3/8" [9.52] 3/8"[9.52] 3/8"[9.52]
Vapor Line OD - In (mm) 3/4"[19.05] 3/4"[19.05] 3/4"[19.05] 7/8"[22.2] 7/8"[22.2] 7/8"[22.2] 7/8"[22.2]
R-22 Charge -Oz (g) 93.64[2650] 102.47[2900] 121.91[3450] 134.28[3800] 148.41[4200] 178.45[5050] 196.11[5550]
Net Dimensions - In (mm) 23*23*31 1/2 30 1/4*30 1/4*27 3/4 30 1/4*30 1/4*31 1/2 30 1/4*30 1/4*31 1/2 30 1/4*30 1/4*35 1/2 30 1/4*30 1/4*31 1/2 30 1/4*30 1/4*35 1/2
W*D*H [585* 585*805] [770* 770*705] [770* 770*805] [770 *770*805] [770 *770*905] [770 *770*805] [ 770 *770*905]
Shipping Dimensions - In (mm) 24 3/4*24 3/4*36 32 3/4*32 3/4*32 1/2 32 3/4*32 3/4*36 32 3/4*32 3/4*36 32 3/4*32 3/4*40 1/2 32 3/4*32 3/4*36 32 3/4*32 3/4*40 1/2
W*D*H [632* 632*919] [832* 832*830] [ 832* 832*930] [832*832*930] [832*832*1030] [832*832*930] [832*832*1030]
Net Weight - Lbs (kg) 156[71] 194[88] 198[90] 203[92] 231[105] 244[111] 258[117]
Approx Shipping Weight - Lbs (kg) 167[76] 209[95] 216[98] 220[100] 249 [113] 262[119] 282[128]
The dimensions for the condensing unit are illustrated in Figure 1. Physical and electrical
specifications are provided in Table 5 for 13 SEER systems respectively.
Model:HC18-60D1VAR
Outdoor Unit With This Indoor Air handler
Model Number
HC18D1VAR HB2400VD1M20
HC24D1VAR HB2400VD1M20
HC30D1VAR HB3600VD1M22
HC36D1VAR HB3600VD1M22
HC42D1VAR HB4800VD1M22
HC48D1VAR HB4800VD1M22
HC60D1VAR HB6000VD1M22
40700 4000 55000 13 Bristol
Table 6:System Cooling Capacity
Air Handler Cooling Capacity (Btu/h) SEER Rated
Sensible Total CFM(Outdoor)
13300
17700
20669
25900
1350.0
1800.0
2100
2700 18000
24000
28000
35000
13
13
13
13
29600
34800 3200
3600 40000
47000 13
13
Compressor
brand
Bristol
Bristol
Bristol
Bristol
Bristol
Bristol
Table 5:
MODEL: HC18D1VAR HC24D1VAR HC30D1VAR HC36D1VAR HC42D1VAR HC48D1VAR HC60D1VAR
Unit Supply Voltage
Normal Voltage Range
Compressor Brand
Minimum Circuit Amps
208/230-1-60
197 - 253
Bristol
8.6 11.6 12.4 15.9 17.7 21.8 33.3
Max Fuse or Max CKT. BKR.
(HACR per NEC )
