HK 980
6 REMOTE CONTROL
Remote Control
Independent Remote Control
The system remote of the HK 980 can control the
amplifier and compatible Tuners, CD Players and
CD Recorders. The remote In jack of units without
an integrated IR receiver must be connected to
the amplifier's remote control output jack so that
the system remote control can operate them.
The Function Table below will show all functions
of the HK 980 and external devices that can be
controlled by the HK 980 remote.
Important Notes:
• To remote control a tuner, CD Recorder or CD
Player, the appropriate input (”TUNER”,
”CDR” or ”CD”) must have been selected with
the source buttons of the remote control
(selecting on the front panel is not sufficient).
• Note that DVD players or tape decks cannot
be controlled by the remote.
• To control a compatible CD Recorder ”CDR”
must be selected as input and the drive to be
controlled (CDP or CDR) must be selected
appropriately with the ”CDP SELECT” or ”CDR
SELECT” buttons.
Operating Conditions
The control unit operates effectively within a
distance of 7 meters and an angle of 30° from
the amplifier. Using the control near fluorescent
lights may shorten this range, as will any dust or
dirt that accumulates on the front of the remote
control or the remote sensor area of the
amplifier. Also avoid blocking the line of sight
between amplifier and remote.
The control unit is powered by two AA batteries,
included with your amplifier. When you replace
weak batteries, replace both at the same time.
When the remote is to be unused for an
extended period, remove the batteries to prevent
damage from corrosion.
Button HK 980 CD Player Tuner
ON Power On - -
OFF Power Off Power Off Power Off
Tuner Select Tuner - Power On
Phono Select Phono - -
TV Select TV - -
Tape Select Tape - -
Aux Select Aux - -
CD Select CD Power On -
Volume + Volume Up - -
CDR Select CDR - -
10+ - Current Track +10 -
Mode Select Mode - -
Folder + - Next Folder -
10- - Current Track -10 -
Volume - Volume Down - -
Folder - - Previous Folder -
Previous JH - Skip Previous -
I Play/Pause - Play/Pause -
Next IK - Skip Next -
Search HH - Fast Reverse -
A Stop - Stop -
Search II - Fast Forward -
Open/Close - Open/Close -
Scroll + - - Tuning Up
Repeat - Repeat Play -
Random - Random Play -
Scroll - - - Tuning Down
0 ~ 9 (Numeric Keys) - Track Select Preset Select
Auto - - Auto Tune
FM Mode - - FM Mode Select
RDS - - RDS Display Select
Mute Mute Sound - -
Band - - Band Select
Select - - Tune Mode Select
Remote button functions
