PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

! On the models supplied with a reducer shelf,
remember that this should be used only for the
Double flame internal (DCDR internal) burner when
you use casserole dishes with a diameter under 12
cm.
To identify the type of burner, refer to the designs in
the section entitled, "Burner and Nozzle
Specifications".

Practical Advice on Using the Half Fish-Kettle
Burner *

The two "Half Fish-Kettle" burners, are eliptic in form
and can be turned up to 90°. This makes the
cooktop more flexible in terms of how it can be
used.

To turn the two burners 90°, proceed as follows:
• Make sure that the burners are cool;
• Lift the burner completely out of its housing;
• Replace it in its housing in the position desired;
• Make sure that the burners are positioned

correctly before use.

In addition, the two burners can be used in tandem
or speartely with cookware of different shapes and
sizes:
• Double burner for a fish-kettle or oval cookware

(Fig.A).

• Double burner for a griddle or rectangular/square

cookware with minimum dimensions of 28x28 cm
(Fig.B)

• Single burner for medium size cookware (diameter

of 16-20 cm) (Fig.C).

• NEVER use the double burner in the

configuration represented in figure D.

Fig. A

Fig. B

Fig. C

Fig. D

Only available on certain models.
