ENGLISH INSTRUCTIONS
IMPORTANT! WRITE DOWN MODEL NUMBER FROM BOX ON
PAGE 1 OF THIS OWNERS MANUAL
1. Remove contents from tank (1).
2. Correctly identify each pole section and mark indicated distance from
ends with tape as shown.
3. IMPORTANT! Center alignment slot of middle pole section (5) in a
lower hole of top pole section (4) as shown. While maintaining
alignment, bounce pole top (4) and middle section (5) together as shown
until they no longer move toward taped reference mark. Upright
assembly. NOTE: Pole sections should have a 3-1/2" (9 cm) minimum
overlap.
4. IMPORTANT! Center alignment slot of lower pole section (6) in a
lower hole of middle pole section (5) as in step 4. While maintaining
alignment, bounce assembly and lower section (6) together as shown
until they no longer moved toward taped reference mark.
NOTE: Pole sections should have a 3-1/2" (9 cm) minimum overlap.
5. Install rod (7) through holes in bottom pole (6) section and eyebolt (8).
6. Install wheel axle (2) through wheel carriage (9) and install wheels (3)
onto wheel axle (3) with spacers (28) as shown. Insert pole assembly
into tank assembly as shown.Secure bottom pole (6) to tank, lower
bracket “A” (36) and wheel bracket as shown, a deep socket is
recommended.
NOTE: Two people recommended for this step.
IMPORTANT! DO NOT OVER TIGHTEN.
7. Secure tank struts (13) to pole. Rotate non-secured ends of tank struts
(13) outward to mounting holes in tank as shown.
WARNING: TIGHTEN BOLT (11) IN LOCK NUT (14) UNTIL FLUSH
(EVEN) WITH LOCK NUT’S OUTER EDGE.
8. Secure non-secured ends of tank struts (13) to tank as shown. Repeat
for opposite side.
WARNING: USE OF THIS PRODUCT WITHOUT PROPER
INSTALLATION OF NET CLIPS, OR WHEN ALL NET CLIPS ARE
NOT PRESENT COULD RESULT IN BODILY HARM. BE SURE TO
FOLLOW DIRECTIONS CAREFULLY.
9. Mount brackets (20), rim spacer (45) and rim (18) to backboard and
finger tighten. NOTE: Final adjustments will be made in Step 12.
IMPORTANT! For spring loaded rim assembly, refer to instructions
included with rim hardware.
10. Support pole and tank assembly over support table. Carefully slide
backboard components onto pole.
WARNING: TWO PERSON MINIMUM REQUIRED FOR THIS
PROCEDURE. NOT FOLLOWING RECOMMENDATION MAY
RESULT IN BODILY INJURY.
WARNING: DO NOT LEAVE ASSEMBLED UNIT UNATTENDED
WHEN EMPTY, MAY TIP OVER.
11. While still in the horizontal position, secure hardware at desired position
as shown and tighten all hardware completely at this time.
12. Install netclips and net as instructed on illustration page.
13. NOTE: Two people recommended for this procedure. Carefully upright
assembly. Apply moving system label (15) to front of pole as shown.
Regulation rim height is 10 feet (3.05 m).
WARNING: DO NOT LEAVE ASSEMBLED UNIT UNATTENDED
WHEN EMPTY, MAY TIP OVER.
14. Place assembled unit to desired location. Fill tank with water (30 gallons
(114 liters)) or sand (360 lb. (163 kg)) and snap tank cap (30) in place.
Insert T-strap (29) through slot on back of base as shown. Secure unit to
ground by twisting tie down stake (27) into ground and hooking T-strap
(29) onto tie down stake (27).
IMPORTANT! Add two gallons (7.6 liters) of non-toxic antifreeze in
sub-freezing climates.
15. Slide framework halves into net and insert reduced end of frame into
expanded end as shown.
NOTE: TABS ON STRAPS SHOULD BE POSITIONED ON THE OUTSIDE
OF NET. FIT OF NET MAY BE TIGHT TO FRAME
16. Attach upper brackets (38) to framework with bolts (39 ), nuts (17) and
washers (12) as shown.
17. Attach lower bracket “B” (37) to framework with bolts (39), nuts (17) and
washers (12) as shown.
18. Lift net assembly into place and attach to unit with hand knobs (41) ,
(42) as shown.
19. Install fiberglass rods (33) into pockets on net. Top and bottom ends of
rods are inserted into holes on framework. Attach pole pad as shown.
20 Attach snap clips on tarp to “D” ring on net as shown.
Thread straps on net through tarp as shown and tighten straps to
desired tarp tension.
02/04 P/N 211583
3
WARRANTY CARD:
Please remember to complete your product
registration form either on-line at:
www.huffysports.com/warrantycard or mail-in
the enclosed postcard.
